BIS ISI Certification for Line Operated Three-Phase AC Motors IS 12615:2018
Line operated three-phase AC motors are widely used in industrial machinery, manufacturing plants, pumping systems, compressors, and other heavy-duty applications. These motors are designed to deliver reliable mechanical power while maintaining high energy efficiency across various industrial operations.
Indian Standard IS 12615:2018 specifies the requirements for energy efficient three-phase squirrel cage induction motors. The standard covers motors with different pole configurations including 2, 4, 6, and 8 poles and frame sizes ranging from 71 up to 315L. These motors typically operate at voltages up to 1000 volts and output ratings from 0.12 kW to 1000 kW.
BIS ISI Mark Certification under IS 12615:2018 ensures that line operated three-phase AC motors meet the required safety, performance, and energy efficiency standards defined by the Bureau of Indian Standards (BIS). It allows manufacturers to legally use the ISI mark and sell compliant motors in the Indian market.
IS 12615:2018 – Key Technical Requirements for Three-Phase AC Motors
- (i) Requirements for energy efficient three-phase squirrel cage induction motors
- (ii) Applicable pole configurations including 2, 4, 6, and 8 pole motors
- (iii) Motor frame sizes ranging from 71 up to 315L
- (iv) Efficiency classification such as IE2, IE3, and IE4 motors
- (v) Rated voltage requirements up to 1000 volts
- (vi) Rated output power range from 0.12 kW to 1000 kW
- (vii) Degree of protection requirements such as IP44 or higher
- (viii) Insulation class requirements including Class B, F, or higher
- (ix) Compliance with dimensional standards such as IS 1231, IS 2223, and IS 2254
Overview of ISI Mark Certification for Line Operated Three-Phase AC Motors
Electric motors are one of the most important components in industrial electrical systems. Motor-driven systems account for nearly 70 percent of the total electricity consumption in many industrial facilities. Therefore, ensuring the energy efficiency and operational safety of motors is critical for reducing energy costs and improving system performance.
IS 12615:2018 establishes energy efficiency requirements and performance parameters for line operated three-phase squirrel cage induction motors. The standard ensures that motors are designed and manufactured to achieve high efficiency levels while maintaining safe operation under industrial working conditions.
BIS ISI certification under the Product Certification Scheme confirms that the motor meets all required technical specifications, testing parameters, and quality control standards. Manufacturers must demonstrate proper manufacturing infrastructure, quality assurance systems, and testing capabilities before BIS grants permission to use the ISI mark.
Process Required for BIS ISI Mark Certification for Three-Phase AC Motors (IS 12615:2018)
Manufacturers seeking BIS ISI certification for line operated three-phase AC motors must follow the BIS Product Certification Scheme (Scheme I). This certification verifies that the motors comply with the technical and energy efficiency requirements specified under IS 12615:2018 before they are introduced into the Indian market.
Estimated Timeline: The BIS ISI certification process generally takes around 30 to 45 days depending on the factory inspection schedule, sample testing process, and documentation verification.
Step-by-Step Certification Process
- Application Submission: The manufacturer submits the BIS application through the Manak Online portal with product details, applicable standard (IS 12615:2018), manufacturing facility information, and quality control documentation.
- Product Testing Preparation: The manufacturer must ensure testing arrangements for performance parameters such as insulation resistance, temperature rise, winding resistance, and efficiency verification.
- Factory Inspection: BIS officials conduct a factory inspection to evaluate production facilities, quality control systems, and in-house testing infrastructure.
- Sample Testing: Product samples are collected during inspection and tested in BIS-recognized laboratories according to the testing methods defined in IS 12615:2018.
- Grant of BIS License: After successful inspection and satisfactory test results, BIS grants the Certification Marks License (CM/L), allowing the manufacturer to affix the ISI mark on three-phase AC motors.
Requirements to Obtain BIS License for Three Phase AC Motors (IS 12615:2018)
- Compliance of three phase squirrel cage induction motors with energy efficiency, construction, and performance requirements defined under Indian Standard IS 12615:2018.
- Availability of appropriate in-house or external testing facilities for parameters such as insulation resistance, winding resistance, temperature rise, and efficiency verification.
- Appointment of qualified quality control personnel responsible for monitoring motor manufacturing processes and ensuring compliance with the applicable BIS standard.
- Implementation of the Scheme of Inspection and Testing (SIT) prescribed by BIS to ensure consistent production quality of three-phase AC motors.
To obtain BIS ISI Mark Certification for line operated three-phase AC motors under the Product Certification Scheme-I, manufacturers must submit documents categorized into the following groups:
- Administrative Documents: Business registration certificates, factory address proof, GST registration, and statutory approvals related to manufacturing operations.
- Technical Details: Motor specifications including pole configuration, rated voltage, output power, insulation class, efficiency class (IE2/IE3/IE4), and protection rating as per IS 12615:2018.
- Quality Control Personnel Details: Qualification and experience details of personnel responsible for product inspection, testing, and quality monitoring.
- Commercial Details: Brand name, trademark details (if applicable), and product authorization documents.
Cost of BIS ISI Certification for Three Phase AC Motors (IS 12615:2018)
The following are indicative government and related charges involved in obtaining BIS ISI Certification for three-phase AC motors under Product Certification Scheme-I. These statutory charges are payable directly to the Bureau of Indian Standards (BIS).
| S. No. | Particular | Amount (INR) | Remarks |
|---|---|---|---|
| 1 | Application Fee | ₹1,000 | Payable to BIS |
| 2 | Inspection / Audit Fee | ₹7,000 | Payable to BIS |
| 3 | Product Testing Fee | As applicable | Depends on motor rating and laboratory testing |
| 4 | Marking Fee | As per actual | Based on BIS fee structure |
Important Note: Product testing as per IS 12615:2018 is a crucial stage in the BIS certification process. BIS may evaluate the manufacturing infrastructure, quality control procedures, and testing capability of the manufacturer before granting the certification license.
Benefits of Getting ISI Mark Certification for Three Phase AC Motors (IS 12615:2018)
Obtaining ISI Mark Certification for line operated three-phase AC motors ensures that the motors comply with Indian energy efficiency and safety standards. Certification improves product credibility and enhances market acceptance across industrial sectors.
1. Compliance with Energy Efficiency Standards
ISI certification ensures motors meet energy efficiency requirements defined under IS 12615:2018.
2. Increased Market Acceptance
BIS-certified motors are widely accepted by industries, infrastructure projects, and government procurement systems.
3. Improved Energy Savings
Energy efficient motors help reduce electricity consumption in industrial motor-driven systems.
4. Stronger Brand Credibility
The ISI mark strengthens brand reputation by confirming compliance with recognized Indian standards.
5. Competitive Advantage in Industrial Markets
Certified motors gain preference among industrial buyers and large infrastructure projects.
Frequently Asked Questions (FAQs) – BIS ISI Certification for Three Phase AC Motors (IS 12615:2018)
1. Which standard applies to energy efficient three phase AC motors in India?
Energy efficient three phase squirrel cage induction motors are covered under Indian Standard IS 12615:2018.
2. What voltage range is covered under IS 12615:2018?
The standard generally applies to motors operating at voltages up to 1000 volts.
3. What efficiency classes are covered under this standard?
IS 12615:2018 covers energy efficiency classes such as IE2, IE3, and IE4 motors.
4. How long does BIS ISI certification for motors take?
The BIS ISI certification process generally takes around 30 to 45 days, depending on inspection scheduling and product testing timelines.
5. What tests are conducted for three phase AC motors?
Tests include winding resistance measurement, temperature rise test, insulation resistance test, high voltage test, no-load test, and overload performance testing.
